Banshee Siren Wiring Diagram

BANSHEE

12V SIREN

GND

20 AMP

AIR HORN

DUAL TONE

LOW FREQUENCY

SPKR 2

SPKR 1

IGN

12GA

POWER HARNESS T56637

FUSE*

100W

SPEAKER

AIR HORN

DUAL TONE

SPEAKER TAP

SPEAKER

LOW FREQUENCY

SPEAKER TAP

IGNITION

SPEAKER

AMPLIFIER

Z3 AMP-2 OR Z3 HUB

CAT5 CABLE

SWITCH 1 SWITCH 2 SWITCH 3 CAT5

SPKTAP2

SPKTAP1

16GA

INPUT/OUTPUT HARNESS T16281

16GA

INPUT/OUTPUT HARNESS T16281

PRIMARY SIREN SPEAKER WIRE 2

PRIMARY SIREN SPEAKER WIRE 1

MOMENTARY SWITCH

NOTE: APPROVED SPEAKER MUST BE USED FOR LOW FREQUENCY OPERATION

MOMENTARY SWITCH

T57555

100W

SPEAKER 2

OPTIONAL SECOND

100W SPEAKER FOR

200W TOTAL

SYSTEM

* USER SUPPLIED FUSE (USE APPRPRIATE SIZE

BASED ON WIRE GAUGE AND LOAD DEMAND)

VEHICLE IGNITION (NOT USED WITH Z3 SYSTEM)

TOGGLE SWITCH (NOT USED WITH Z3 SYSTEM)

BATTERY

+12V

AMPLIFIER POWER
